Sensor de Temperatura y Humedad del Suelo (Tipo Conducto Multicapa)
Descripción e commerce
Sensor de Temperatura y Humedad del Suelo (Tipo Conducto Multicapa). Detalle del Producto Descripción Detallada The soil temperature and humidity sensor based on FDR (Frequancy Domain Reflection) principle, using the FDR layered tube type soil moisture measuring method, according to the f. Capable of simultaneous measurement of different depth of soil moisture and soil temperature. Codigo interno C-002266.
- This series of products can be widely used in drought monitoring, soil research, intelligent irrigation, agricultural production prediction and landslides
- Beneficios Clave Respuesta rápida para mediciones dinámicas
- Beneficios Clave Respuesta rápida
| Tipo de Equipo: Detector de Fugas de Caldera |
Descripción Detallada
The soil temperature and humidity sensor based on FDR (Frequancy Domain Reflection) principle, using the FDR layered tube type soil moisture measuring method, according to the frequency change of the electromagnetic wave emitted by the detector in different dielectric coefficient material, calculated from the measured soil moisture. Capable of simultaneous measurement of different depth of soil moisture and soil temperature. This series of products can be widely used in drought monitoring, soil research, intelligent irrigation, agricultural production prediction and landslides.
Beneficios Clave
Respuesta rápida para mediciones dinámicas.
Excelente estabilidad en mediciones.
Ampliamente utilizado en diversas aplicaciones.
Aplicaciones Principales
- Agricultural Irrigation
- Environmental Protection
- Grassland & Pasture
- Soil Science Research
- Drought monitoring
- Intelligent irrigation
- Agricultural production prediction
- Landslides
Galería de Imágenes
Especificaciones Técnicas
| Range | 0-60%（m³/m³） / -40℃-+80℃ |
|---|---|
| Accuracy | ±3%(0-35%)±5%(35%-60%) / ±0.5℃@25℃ |
| Resolution | 0.1% / 0.1℃ |
| Output signal | RS485 |
| Measurement level | 3 / 4 / 5 / 6 |
| Response time | <1s |
| Supply | 12-24VDC |
| MTTF | ≥25000h |
| Housing | PVC |
| Operating temperature | -40℃-+80℃ |
| Ingress protection | IP68(underground) |
| Storage | 10-60℃@20%-90%RH |
| Measurement level: 3 | 10cm-20cm-30cm |
| Measurement level: 4 | 10cm-20cm-30cm-40cm |
| Measurement level: 8 | 10cm-20cm-30cm-40cm-50cm-60cm-70cm-80cm |
| Measurement level: 10 | 10cm-20cm-30cm-40cm-50cm-60cm-70cm-80cm-90cm-100cm |
