Sensor de Velocidad del Viento (Para Tuberías HVAC)
Descripción e commerce
Sensor de Velocidad del Viento (Para Tuberías HVAC). Detalle del Producto Descripción Detallada B-01-05-4035 Pipe Wind Speed Sensor is designed on the basis of the principle of hot-wire, the probe and housing adopt resistance to high temperature and anti-corrosion material. In the bad environment, it also can work stablely and reliably.It can quickly and accurately tiny air flow measurement. Codigo interno C-002239.
- Detalle del Producto Descripción Detallada B
- 4035 Pipe Wind Speed Sensor is designed on the basis of the principle of hot
- wire, the probe and housing adopt resistance to high temperature and anti
| Tipo de Equipo: Detector de Fugas de Caldera |
Descripción Detallada
B-01-05-4035 Pipe Wind Speed Sensor is designed on the basis of the principle of hot-wire, the probe and housing adopt resistance to high temperature and anti-corrosion materials . In the bad environment, it also can work stablely and reliably.It can quickly and accurately tiny air flow measurement. The product has realized high precision and high resolution through internal linear compensation and temperature calibration, and long term stability is extremely good, which should be installed directly.
Beneficios Clave
Bajo umbral de inicio para mediciones.
Fuerte capacidad de resistencia a la corrosión.
Varias señales de salida opcionales.
Aplicaciones Principales
- Sistemas HVAC
- Medición de flujo de aire en conductos
- Automatización de edificios
Galería de Imágenes
Especificaciones Técnicas
| Output | 4-20mA,0-10V,RS485,0-5V |
|---|---|
| Supply | 12-24VDC |
| Range | 0-5m/s,0-10m/s,0-20m/s,0-30m/s |
| Response time | <1s |
| Accuracy(0-50℃) | ±3%FS |
| Resolution | <0.05m/s |
| Power consumption | <80mA@24VDC(4-20mA)<60mA@24VDC(RS485,0-5V,0-10V) |
| Long-term stability | ±0.1m/s per year |
| Display | optional |
| Ingress Protection | IP55 |
| OperatingTemperature | -20℃-+70℃ |
| Main material | ABS |
| Probe length | 210mm typ., Other length can be customized |
| Storage condition | 10℃-50℃@20%-90%RH |
