HM-5100SW

AEwinTM is a Windows®-based program for real-time “simultaneous” Acoustic Emission (AE) feature and waveform processing, display, fast storage, and replay. It is used for true, real-time operation and control with your MISTRAS AE Systems (Express-8, PCI2, SAMOS, SH II, SH III, AE USB Node, and Wireless AE Node). AEwinTM is easy to learn, operate and use. The software has all the acquisition, graphing and analysis capabilities that customers have come to expect in an AE system, plus many more features to ease your data analysis and visualization tasks.

AEwinTM offers highly flexible AE display and analysis, with exceptional 2D and 3D graphing and manipulation capabilities, and a framework for easily creating and customizing graph display. Graph types include 2D histograms, line plots and point plots, 3D graphs, waveforms, FFTs, and multiple plots on a single graph with coloring options. All graphs can be infinitely zoomed, maximized to full screen, and offer cursor readout capability, allowing for close-up data analysis. Additionally, AEwinTM includes enhanced processing features such as Hit-Event Linking and built-in filtering functions (both graphical filters and Post Filtering).

AEwin’s standard configuration includes both zonal and linear location determination modes. For more comprehensive location determination capabilities, optional “Full Location” software adds 2D Planar Location capabilities. For 3D location, “3D Location” and “Spherical 3D location” options are also available.

Multiple copies of AEwin can be run at once, one for acquisition with full display and analysis capabilities, and one or more as Replay for additional analysis purposes.
