Juego de dendrómetro pivotante - PDS40P-SET
 |  |  |  |
| Pivot dendrometer for small diameters | EMS PDS40S SDI-12 pivot dendrometer | Pivot dendrometer sensor on tree | Pivot dendrometer sensor on tree |
- manufactured by
- digital sensor for accurate monitoring of stem diameter
- intended for stem diameter from 5 to 40 mm
- individually calibrated
- non invasive fixing
- digital SDI-12 output
- intended for long-term monitoring
- low maintenance and easy installation
Specification
| Output | SDI-12 version 1.3 |
| Measuring range | 5 to 40 mm |
| Resolution | 1.24 μm |
| Accuracy | better than 0.3 mm |
| Protection rating | IP67 |
| Weight of sensor | 160 g |
| Operating environment temperature | –40 to 60 °C |
| Operating environment humidity | 0 to 100% |
Precise stem diameter records
- no effect on tree growth
- efficient tool for field measurement
- comprises information about growth, water stress and freezing up of the stem
- low maintenance and energy requirements in comparison with sophisticated measuring systems like sap flow for instance
- together with the measurement of soil water potential it gives realistic picture of drought stress and the tree response to it
SDI-12 data output
- asynchronous serial communications protocol for intelligent micro-processor based sensors
- sensor typically takes a measurement, makes computations based on the raw sensor reading, and outputs the measured data in engineering units
- allows connection of set of sensors serially on one cable line
- for more informations look at SDI-12 website
Download
Datasheet Dendrometer Installation
SKU: C-002780
| | | |
| Pivot dendrometer for small diameters | EMS PDS40S SDI-12 pivot dendrometer | Pivot dendrometer set on tree | Pivot dendrometer set on tree |
- manufactured by
- sensor for accurate monitoring of stem diameter
- intended for stem diameter from 5 to 40 mm
- individually calibrated
- non invasive fixing
- digital SDI-12 output
- intended for long-term monitoring
- low maintenance and easy installation
Specification
| Output | SDI-12 version 1.3 |
| Measuring range | 5 to 40 mm |
| Resolution | 1.24 μm |
| Accuracy | better than 0.3 mm |
| Protection rating | IP67 |
| Weight of sensor | 160 g |
| Operating environment temperature | –40 to 60 °C |
| Operating environment humidity | 0 to 100% |
Precise stem diameter records
- no effect on tree growth
- efficient tool for field measurement
- comprises information about growth, water stress and freezing up of the stem
- low maintenance and energy requirements in comparison with sophisticated measuring systems like sap flow for instance
- together with the measurement of soil water potential it gives realistic picture of drought stress and the tree response to it
SDI-12 data output
- asynchronous serial communications protocol for intelligent micro-processor based sensors
- sensor typically takes a measurement, makes computations based on the raw sensor reading, and outputs the measured data in engineering units
- allows connection of set of sensors serially on one cable line
- for more informations look at SDI-12 website
