EMScloud SoilTemp 01 - EMS-SOILTEMP-01
 |  |  |  |
| Data transmitting air and soil temperature sensor | Data transmitting air and soil temperature sensor | Data transmitting air and soil temperature sensor | Supporting pin with built-in temperature sensor on the bottom end) |
- manufactured by
- device with air and soil temperature sensor transmitting data to internet via SigFox network
- stick-in supporting pin with built-in temperature sensor on the bottom end (anchor tip)
- intended for long-term monitoring
- 20-minutes time resolution
- powered by long lasting Lithium-ion battery
- low maintenance and easy installation
- data visualization, archiving and downloading fully supported by EMScloud Internet application
- Mini32 software support
Specification
| Temperature measuring interval | 20 min |
| Sending interval | 60 min |
| Air temperature range | –40 to 60 °C |
| Soil temperature range | –20 to 80 °C |
| Temperature resolution | ± 0.15 °C |
| Battery lifetime | more than 2 years |
| Protection rating | IP68 |
| Operating temperature | –40 to 60 °C (soil temperature probe – 40 to 80 °C) |
| Operating humidity | 0 to 100% |
Online communication
- data transmition performed via Sigfox protokol
Online data visualization on EMScloud website
- measured values clearly displayed in graphs
- online value agregation and integration
- alerts about failures and unexpected events
- view all data in web browsers on different devices
- fast download in several formats
Mini32 software
- graphically oriented software intended for work with long time series
- fast calculation of hourly, daily, montly values
- fast brief statistics
- built-in efficient commands for summation and min-max-average calculation
- for more informations look at EMSsoftware
Download
Datasheet
Transmitter battery replacement instructions Accessories
 |  |
| Battery for Sigfox transmitter | Dessiccant bag |
SKU: C-002805
| | | |
