EMScloud Soilset 22
 |  |  |  |
| Data transmitting device EMScloud SoilSet 22 with sensor CS650 | Data transmitting device EMScloud SoilSet 22 with sensor CS650 | Data transmitting device EMScloud SoilSet 22 with sensor CS650 | Data transmitting device EMScloud SoilSet 22 with sensor CS650 |
 | |||
| Data transmitting device EMScloud SoilSet 22 with sensor CS650 |
- manufactured by
- device with sensor CS650 transmitting data to internet via SigFox network
- intended for long-term accurate monitoring of VWC, electrical conductivity and sensor temperature
- 30-minutes time resolution
- powered by long lasting Lithium-ion battery
- low maintenance and easy installation
- data visualization, archiving and downloading fully supported by EMScloud Internet application
- Mini32 software support
Specification
| Measuring interval | 30 min |
| Sending interval | 60 min |
| Volumetric water content range | 0 to 0.6 m3/m3 |
| Bulk electrical conductivity range | 0 to 3 dS/m |
| Sensor temperature range | –50 to 70 °C |
| Battery lifetime | more than 2 years |
| Protection rating | IP68 |
| Size of transmitter (diameter x length) | 90 x 115 mm |
| Weight of transmitter (without pin) | ca 300 g |
| Sensor cable length | 3 m (special lengths on request) |
| Operating environment temperature | –40 to 60 °C |
| Operating environment humidity | 0 to 100% |
Campbell Scientific CS650 sensor
- consists of two 30-cm-long stainless steel rods
- measurement of VWC and electrical conductivity in larger sample (30 cm profile) reduces error
- integrated measurement of temperature in sensor body
Online communication
- data transmition performed via Sigfox protokol
Online data visualization on EMScloud website
- measured values clearly displayed in graphs
- online value agregation and integration
- alerts about failures and unexpected events
- view all data in web browsers on different devices
- fast download in several formats
Mini32 software
- graphically oriented software intended for work with long time series
- fast calculation of hourly, daily, montly values
- fast brief statistics
- built-in efficient commands for summation and min-max-average calculation
- for more informations look at EMSsoftware
Download
Datasheet
Sensor installation guide Accessories
 |  |  |
| Insertion guide tool for CS6XX sensors | Battery for Sigfox transmitter | Dessiccant bag |
