EMScloud RainSet 02
 |  |  |
| Online Precipitation gauge RainSet_01 | Online Precipitation gauge RainSet_01 | Online Precipitation gauge RainSet_01 |
- manufactured by
- precipitation and temperature sensor transmitting data to internet via SigFox network
- precipitation resolution 0.2 mm
- intended for long-term monitoring
- low maintenance and easy installation
- indication of tilt
- data visualization, archiving and downloading fully supported by EMScloud Internet application
- long battery lifetime
- Mini32 software support
Specification
| Temperature measuring interval | 20 min |
| Precipitation sumation interval | 10 min |
| Sending interval | 60 min (10 min during rain event) |
| Collecting area | 200 cm2 |
| Precipitation resolution | 0.2 mm |
| Battery lifetime | more than 2 years |
| Temperature accuracy | ± 0.15 °C |
| Protection rating | IP68 |
| Size (without supporting pin) | 250 x 250 x 160 mm |
| Weight (without supporting pin) | 680 g |
| Operating environment temperature | –40 to 60 °C |
| Operating environment humidity | 0 to 100% |
Online communication
- internal tip counter ensures the correct absolute sum of precipitation independently on transmitter signal
- for the most up-to-date information about precipitation the transmitting interval change to 10 min during raining event
- data transmition performed via Sigfox protokol
Online data visualization on EMScloud website
- measured values clearly displayed in graphs
- online value agregation and integration
- alerts about failures and unexpected events
- view all data in web browsers on different devices
- fast download in several formats
Mini32 software
- graphically oriented software intended for work with long time series
- fast calculation of hourly, daily, montly values
- fast brief statistics
- built-in efficient commands for summation and min-max-average calculation
- for more informations look at EMSsoftware
Download
Datasheet
Maintenance notes
Maintenance notes CZ
Transmitter battery replacement instructions Accessories
 |  |
| Battery for Sigfox transmitter | Dessiccant bag |
SKU: C-002812
| | |
