Piranómetro EMS 11S (SDI-12)
 |  |  |
| Pulse/SDI-12 interfece | Pulse/SDI-12 interfece with Pronamic Pro raingauge | Pulse/SDI-12 interfece with MetOne 370D raingauge |
- interface from pulse to SDI-12 digital output
- intended for tipping bucket rain gauges with reed contact
- watertight enclosure IP 68
- manufactured by
Specification
| Output | SDI-12 ver. 1.3 |
| Input | Tipping bucket rain gauge contact (maximal serial resistance 1 kOhm) |
| Data output | Sum of pulses since the last measur. command |
| Power supply voltage | 5 to 16 V (permanent) |
| Protection rating | IP68 |
| Size (diameter x length) | 22 x 130 mm (incl. connectors) |
| Weight | 40 g |
| Operating environment temperature | –40 to 60 °C |
| Operating environment humidity | 0 to 100% |
Download
Datasheet
SDI-12 commands
SKU: C-002825
| | |
