Piranómetro EMS 11
 |  |  |  |
| Pyranometer EMS11 | Glass optics | Connector in sensor body | Mounting on radiation shield Al 061 |
- manufactured by
- small sensor for measurement of global radiation
- glass optics
- silicon semiconductor photovoltaic detector
- voltage output
- compatible with radiation shields with holder AL 0171
Specification
| Output | Voltage |
| Sensitivity | 20 mV per 1000 W/m2 |
| Linearity | Better than 1% |
| Cosine error | <10% up to 85° angle of incidence |
| Protection rating | IP68 |
| Size (diameter x length) | 22 x 39 mm |
| Weight | 30 g |
| Operating environment temperature | –40 to 60 °C |
| Operating environment humidity | 0 to 100% |
Glass optics
- more stable than plastic optics
- less frequent calibration requirements
- great cosine response
Horizontally adjustable mounting
- plate on top of stick
- verically sliding plate on pin
- plate compatible with radiation shield
Download
Datasheet Accessories
Compatible with
Similar Products
SKU: C-002826
| | | |
