Dendrómetro de banda para sistema de flujo de savia EMS 81 DR26E
 |  |  |  |
| Dendrometer Increment sensor DR26E | Dendrometer Increment sensor DR26E | Non-invasive fixing of dendrometer increment sensor DR26E on tree | Dendrometer Increment sensor DR26E |
- manufactured by
- sensor for accurate monitoring of the tree trunk circumference increment
- intendef for Sap Flow systems EMS 8X line
- no upper limit in stem diameter
- non invasive fixing
- low maintenance and easy installation
- increment range 64 mm
- step-less reading
Specification
| Output | voltage divider |
| Circumference increment measuring range | 64 mm |
| Linearity | 1 % of full scale |
| Resolution | step-less |
| Protection rating | IP68 |
| Weight | 350 g |
| Operating environment temperature | –40 to 60 °C |
| Operating environment humidity | 0 to 100% |
Non invasive fixing by tape
- no effect on tree growth
- integrated value for whole radial profile in measured height
- almost identical thermal expansion of wood and stainless steel
Precise increment records
- efficient tool for field measurement
- comprises information about growth, water stress and freezing up of the trunk
- together with sap flow and soil water potential measurement it gives realistic picture of drought stress and the tree response to it
Download
Datasheet
Installation manual Dendrometer Installation
Compatible with
Accessories
SKU: C-002830
| | | |
| Dendrometer Increment sensor DR26P | Dendrometer Increment sensor DR26P | Non-invasive fixing of dendrometer increment sensor DR26P on tree | Dendrometer Increment sensor DR26P |
- manufactured by
- sensor for accurate monitoring of the tree trunk circumference increment
- intendef for Sap Flow systems EMS 8X line
- no upper limit in stem diameter
- non invasive fixing
- low maintenance and easy installation
- increment range 64 mm
- step-less reading
Specification
| Output | voltage divider |
| Circumference increment measuring range | 64 mm |
| Linearity | 1 % of full scale |
| Resolution | step-less |
| Protection rating | IP68 |
| Weight | 350 g |
| Operating environment temperature | –40 to 60 °C |
| Operating environment humidity | 0 to 100% |
Non invasive fixing by tape
- no effect on tree growth
- integrated value for whole radial profile in measured height
- almost identical thermal expansion of wood and stainless steel
Precise increment records
- efficient tool for field measurement
- comprises information about growth, water stress and freezing up of the trunk
- together with soil water potential measurement it gives realistic picture of drought stress and the tree response to it
