| Sap flow sensor SF64 installed on branch | Sap flow system EMS SF 64 with datalogger | Measuring unit MicroSet 6X with embedded datalogger | Sap Flow sensor SF64 |
 |  | ||
| Powering of easuring units MicroSet 6X | Sap Flow system installed on hop stems |
- manufactured by
- stand-alone sapflow measuring unit with embedded datalogger
- based on tissue heat balance (THB) method with variable power and constant dT
- external heating and internal temperature measuring of stem tissue
- two dimensions of sap flow sensors according to the stem thickness (6 to 12 and 10 to 20 mm)
- values of kg/h per plant
- datalogging measuring unit MicroSet 6X
- input for pivot dendrometer sensor
- constant temperature difference adjustable to 2, 4 or 8K
- infrared wireless data access
- Mini32 software support
Precise tool for assessment of tree water regime
- efficient tool for field measurement
- no overheating of stem tissues
- gives realistic picture of tree water status
- calculating of NET sapflow possible using the Mini32 software with built-in commands
Sap flow system EMS SF 64 main parts
- MicroSet 6X controlling and datalogging unit
- sap flow sensor SF 64 (for stems 6-12 or 10-20 mm)
- weather shields, connecting cables and powering
- stem diameter sensor PDS40P
Mini32 software
- graphically oriented software intended for work with long time series
- fast automatic subtraction of sap flow baseline
- fast brief statistics
- built-in efficient commands for calculating of baseline
Download
Datasheet
User manual
Sensor SF64 installation
SKU: C-021044
| | | |
| Sap flow sensor SF64 installed on branch | Sap flow system EMS SF 64 with datalogger | Measuring unit MicroSet 6X with embedded datalogger | Sap Flow sensor SF64 |
| | ||
| Powering of easuring units MicroSet 6X | Sap Flow system installed on hop stems |
- manufactured by
- stand-alone sapflow measuring unit with embedded datalogger
- based on tissue heat balance (THB) method with variable power and constant dT
- external heating and internal temperature measuring of stem tissue
- two dimensions of sap flow sensors according to the stem thickness (6 to 12 and 10 to 20 mm)
- values in kg/h per plant
- datalogging measuring unit MicroSet 6X
- input for pivot dendrometer sensor
- constant temperature difference adjustable to 2, 4 or 8K
- infrared wireless data access
- Mini32 software support
Precise tool for assessment of tree water regime
- efficient tool for field measurement
- no overheating of stem tissues
- gives realistic picture of tree water status
- calculating of NET sapflow possible using the Mini32 software with built-in commands
Sap flow system EMS SF 64 SDI-12 main parts
- MicroSet 6X controlling and datalogging unit
- sap flow sensor SF 64 (for stems 6-12 or 10-20 mm)
- weather shields, connecting cables and powering
- stem diameter sensor PDS40P
Mini32 software
- graphically oriented software intended for work with long time series
- fast automatic subtraction of sap flow baseline
- fast brief statistics
- built-in efficient commands for calculating of baseline
