SM 100 Soil moisture probe Meter Group Teros 12 Soil water potential sensor Watermark Soil water potential sensor Delmhorst GB1/GB2 Soil water potential sensor Meter Group Teros 21 Manual band dendrometer EMS DB20 Band dendrometer for large trees EMS DR26 Band dendrometer for large trees EMS DRS26 Band dendrometer for sap flow system EMS 81 DR26E Pivot diameter sensor EMS PDS40 P Pivot diameter sensor EMS PDS40 A Pivot diameter sensor EMS PDS40 S Water level sensor Stork SLS-D Apogee sensors Sap flow four-component net radiometer – separate measurements of global and reflected solar and downwelling and upwelling longwave radiation thermopile measuring principle voltage output manufactured by Kipp & Zonen compatible with EMS dataloggers and accessories for more informations look at manufacturer website Specification Output Voltage Spectral range (solar) 0.3 to 2.8 μm Sensitivity (solar) 10-20 μV/W/m 2 Spectral range (longwave) 4.5 to 42 μm Sensitivity (longwave) 5-15 μV/W/m 2 Protection rating IP67 Weight (without cable) 850 g Operating environment temperature –40 to 80 °C Operating environment humidity 0 to 100% Download Instruction Sheet – CNR4 User manual – CNR4 Net Radiometers Brochure – Kipp & Zonen
