Concrete Moisture Encounter X5 - CMEX5 - Measuring Range:
| Depth of penetration in concrete: |
approx. ¾" (20mm) |
| Moisture content for Concrete: |
0 → 6.9 % |
| Comparative for Gypsum floor screed: |
0 → 12 |
| CM Equiv Anhydrite/Concrete: |
0→2.7 / 0→4.3 |
| Reference scale: |
0 → 100 |
| Relative Humidity: |
0 → 99% |
| (with optional Hygro-i2 ® probe): |
Humidity accuracy: 0% → 99%RH +/- 2% @ 25°C / 77°F |
| Moisture content for wood (with optional wood pin probes): |
5 → 30 % |
Moisture Encounter 5 - ME5 - Measuring Range:
| Wood Moisture Content: |
5 to 30% |
| Reference scale for building materials: |
0 to 100 |
| Depth of penetration: |
Shallow signal: up to ⅜” (10mm)
Deep signal: up to 1¼" (30mm)
|
Feedback Datalogger DL-RHTX Measuring Range:
| Memory: |
100,000 data point entries (samples of Ambient RH and temperature; SurfaceTemperature) |
| Logging Rate: |
Logger interval adjustable between 10 minutes and 1 hour |
| Transmission Range: |
Up to 165ft (50m) line-of-sight |
| Bluetooth: |
BLE Bluetooth Low Energy 4.2 compliant |
Relative Humidity Sensor Specifications:
| Range: |
0 to 100%RH |
| Accuracy: |
±1.5%RH Range 0% to 80%RH ±2.0%RH Range 80% to 99%RH (@ 77ºF (25ºC)) |
| Resolution: |
0.1% over the complete range |
| Drift: |
<0.25%RH per year |
Temperature Sensor Specifications:
| Range: |
-4ºF to 158ºF( -20°C to 70°C) |
| Accuracy: |
±0.1ºF Range -4ºF to 158ºF(±0.1 °C Range -20°C to 70°C) |
| Sensor Protection: |
PTFE Film protects sensor opening from water & dust Drift: <0.04ºF (0.03ºC) per year |
| Drift: |
<0.04ºF (0.03ºC) per year |
Infrared Thermometer IRT2
| Temperature range: |
-58ºF ~ 1202ºF (-50 to 650 ºC) |
| Distance to Spot ratio: |
D:S = 12:1 |
| Display resolution: |
0.1 ºF(0.1ºC) <1000 1ºC >1000 |
| Accuracy for targets: |
Assumes ambient operating temperature of 73 to 77ºF (23 to 25 ºC) -58ºF ~ 68ºF (-50 ~ 20ºC)
±4.5ºF (2.5ºC) 68ºF ~572ºF (20ºC ~300ºC) ±1.0% ± 1.8ºF (1.0ºC) 572ºF ~ 1202ºF (300ºC ~650ºC) ±1.5%
|
| Repeatability: |
-58~68ºF (-50~20ºC) : ± 2.3ºF (1.3ºC) 68~1202ºF (20~650ºC) : ±0.5% or ±0.9ºF (0.5ºC) |
| Response time: |
150ms |
| Spectral response: |
8~14um |
| Emissivity: |
Digitally adjustable from 0.10 to 1.0 |
| Over range indication: |
LCD will show “----” |
| Polarity: |
Automatic (no indication for positive polarity); Minus (-) sign for negative polarity |
| Diode laser output: |
<1mW,Wavelength 630~670nm, Class 2 laser product |
| Operating temp.: |
32 to 122ºF ( 0 to 50ºC) |
| Storage temp.: |
14 to 140ºF (–10 to 60ºC) |
| Relative humidity: |
10%~90%RH operating, <80%RH storage |
| Power supply: |
9V battery, NEDA 1604A or IEC 6LR61, or equivalent |
| Safety: |
“ CE ” Comply with EMC |
Specifications of Kit:
| Size: |
20.5” x 18.9” x 5.9” (52cm x 48cm x 15cm) |
| Weight: |
13.2 lbs (6kg) |
| Power: |
5 x AA batteries, 1 x 9 volt PP3 battery |
