SM 100 Soil moisture probe Meter Group Teros 12 Soil water potential sensor Watermark Soil water potential sensor Delmhorst GB1/GB2 Soil water potential sensor Meter Group Teros 21 Manual band dendrometer EMS DB20 Band dendrometer for large trees EMS DR26 Band dendrometer for large trees EMS DRS26 Band dendrometer for sap flow system EMS 81 DR26E Pivot diameter sensor EMS PDS40 P Pivot diameter sensor EMS PDS40 A Pivot diameter sensor EMS PDS40 S Water level sensor Stork SLS-D Apogee sensors Sap flow Pivot dendrometer for small diameters EMS PDS40S SDI-12 pivot dendrometer Pivot dendrometer sensor on tree Pivot dendrometer sensor on tree manufactured by digital sensor for accurate monitoring of stem diameter intended for stem diameter from 5 to 40 mm individually calibrated non invasive fixing digital SDI-12 output intended for long-term monitoring low maintenance and easy installation Specification Output SDI-12 version 1.3 Measuring range 5 to 40 mm Resolution 1.24 μm Accuracy better than 0.3 mm Protection rating IP67 Weight of sensor 160 g Operating environment temperature –40 to 60 °C Operating environment humidity 0 to 100% Precise stem diameter records no effect on tree growth efficient tool for field measurement comprises information about growth, water stress and freezing up of the stem low maintenance and energy requirements in comparison with sophisticated measuring systems like sap flow for instance together with the measurement of soil water potential it gives realistic picture of drought stress and the tree response to it SDI-12 data output asynchronous serial communications protocol for intelligent micro-processor based sensors sensor typically takes a measurement, makes computations based on the raw sensor reading, and outputs the measured data in engineering units allows connection of set of sensors serially on one cable line for more informations look at SDI-12 website Download Datasheet Dendrometer Installation
