Pyranometer EMS 11 Product Group: Sensors Pyranometer EMS 11 Pyranometer EMS 11S PAR sensor EMS 12 PAR sensor EMS 12S Pyranometer Hukseflux SR05-A1 Pyranometer MetOne 094 Net radiometer NR Lite 2 Net radiometer NR Lite 2 SDI-12 Net radiometer Hukseflux NR 01 Net radiometer K&Z CNR4 Net radiometer Apogee SN-500 Air T and RH sensor EMS 33H Air T and RH sensor EMS 33S Air T, RH and pressure sensor EMS 36S Air T and RH sensor Vaisala HMP155 Wind sensor MetOne 034B Ultrasonic anemometer Meter Group Atmos 22 Ultrasonic anemometer Gill WindSonic Rain gauge MetOne 370D Rain gauge Pronamic Pro Throughfall colector EMS 1600 Soil heat flux sensor Hukseflux HFP01 Soil heat flux sensor Hukseflux HFP01 SDI-12 Soil heat flux sensor Hukseflux HFP01SC Soil temperature sensor Pt100/8 Soil temperature sensor Pt1000/8 Soil temperature sensor LM34/8 Double temperature sensor RTDx2/S Thermocouple sensor EMS TC-T Soil moisture probe Campbell CS 616 Soil moisture probe Campbell CS 650/655 Soil moisture probe Truebner SMT 100 Soil moisture probe Spec.
Tech.
SM 100 Soil moisture probe Meter Group Teros 12 Soil water potential sensor Watermark Soil water potential sensor Delmhorst GB1/GB2 Soil water potential sensor Meter Group Teros 21 Manual band dendrometer EMS DB20 Band dendrometer for large trees EMS DR26 Band dendrometer for large trees EMS DRS26 Band dendrometer for sap flow system EMS 81 DR26E Pivot diameter sensor EMS PDS40 P Pivot diameter sensor EMS PDS40 A Pivot diameter sensor EMS PDS40 S Water level sensor Stork SLS-D Apogee sensors Sap flow Pyranometer EMS11 Glass optics Connector in sensor body Mounting on radiation shield Al 061 manufactured by small sensor for measurement of global radiation glass optics silicon semiconductor photovoltaic detector voltage output compatible with radiation shields with holder AL 0171 Specification Output Voltage Sensitivity 20 mV per 1000 W/m 2 Linearity Better than 1% Cosine error <10% up to 85° angle of incidence Protection rating IP68 Size (diameter x length) 22 x 39 mm Weight 30 g Operating environment temperature –40 to 60 °C Operating environment humidity 0 to 100% Glass optics more stable than plastic optics less frequent calibration requirements great cosine response Horizontally adjustable mounting plate on top of stick verically sliding plate on pin plate compatible with radiation shield Download Datasheet Accessories Radiation shields and holders Compatible with Datalogger Microlog V3A Datalogger GreyBox GSM – custom tailored Datalogger line RailBox Similar Products Pyranometer EMS 11S PAR sensor EMS12
